Needle & Metering valves

A wide range of designs including 2 way, 3 way, multi port, block and bleed, Specifically designed adapted and certified low temperature valves offering safe, efficient service for temperatures to -196C. Needle Valve PDA by ABS certified MSS-SP-99 as per API622 / ISO 15848. Certified for CNG applications (NGV3.1, ECE R110, ISO15500) IBR Certifcation available, working pressure to 15,000psig (1034 barg) up to 30,000psig (2068barg) available on request, End connection and valve material to customer requirments, Heat Code Traceability

Pressure ball valves

Standard two, three and four way designs, Floating and standard designs to BS EN ISO 17292 / API 6D, PDA by ABS, API 607, ISO10497

Manifold

Available in 4 designs. Separately Mounted, Direct T type mounting, Direct H type mounting, Co Planar Manifolds. Coated and rolled stem threads, swivelling hardened design to provide long life and low wear.Pipe sealing prevents stem blowout and reduces gland leakage. Aramco 9COM approved to 6000002865

Instrumentation non return valves

PDA by ABS, available in a variety of designs and tube end connections. Standard cracking pressure 0.3-0.5 kg/cm2 up to 2kg/cm2 offered for special applications. Working pressure to 6000 psig (414barg) Materials to customers requirements. Heat Code Traceability

Block & bleed valves

A Block and bleed manifold combines one or more block/isolate valves, usually ball valves, and one or more bleed/vent valves, usually ball or needle valves, into one component for interface with other components of a hydraulic system

Instrument hookup valves

EIL Approved prefabricated instruments hookups, each hookup is custom designed for the customer / application. 3D and PDMS / PDS modelling to facilitate alignment with plant layout, complete traceability and simplified packaging as per TAG numbers
